Hyatt Place Nashville PT Repair
Concrete access and restoration were coordinated with specialist tendon replacement and stressing at Hyatt Place Nashville.
Delta Structural Technology completed post-tension repair work at Hyatt Place in Nashville. The planned scope combined concrete opening and repair with tendon replacement and stressing by a specialist subcontractor. The project centered on the sequence between access to the existing tendon, replacement of the cable, and restoration of the surrounding concrete.
- Market
- Hospitality & Recreation
- Services
- Post-tension tendon repair
- Location
- Nashville, Tennessee
Project challenge
Tendon repair involves more than exchanging a cable. The surrounding concrete must be opened sufficiently for the specialist work, and the affected area then needs repair. At Hyatt Place, the project planning separated those construction activities from the subcontracted removal, replacement, and stressing operations. Potential additional tendons were to be handled through a separately defined scope.
Project approach
Delta’s planning identified removal of the existing cable, pulling in a replacement, and stressing as the specialist tendon activities. Delta’s crew allowance addressed the associated chipping and repair work. The proposed sequence therefore coordinated concrete access and restoration with the post-tension specialist, rather than treating the cable operation as an isolated task.
Delivery and coordination
The team’s planning correspondence distinguished the initial tendon scope from potential additional cables awaiting information. This was important for coordinating crew work and the specialist’s operations around the same repair locations. The practical interface was clear: concrete opening work had to enable the tendon operation, and restoration had to follow the work needed at those locations.
Project significance
Hyatt Place illustrates the interdependence of concrete repair and post-tension specialist work. A coordinated sequence connects access, cable replacement, stressing, and restoration. Defining the tendon scope and any additions also helps the construction team plan work at each location without assuming all cables receive the same intervention.
